MK657

The special pattern design with 3D cutter grooves improved the stability of grasp performance on snow road.

The optimized arrangement of studs minimized the disturbing noise waveThe optimizedwhile increased thegrasp force on ice road. It also improved the driving comfort for the driver.

size

Rim Diameter	Size	LI/SI	Measuring Rim	Inflatable Section Width(mm)	Overall Diameter(mm)	Max. Load(kg）	Max. Pressure(kPa)
17″	215/65R17	103T XL	6.5J	221	712	875	340
17″	235/45R17	97T XL	8J	236	644	730	340
18″	215/55R18	95T	7J	226	693	690	300
	235/50R18	101T XL	7.5J	245	693	825	340
	245/40R18	97T XL	8.5J	248	653	730	340
	225/55R18	102T XL	7J	233	705	850	340
	255/60R18	112T XL	7.5J	260	763	1120	340
19″	245/45R19	98T	8J	243	703	750	300
	255/50R19	103T	8J	265	739	875	300
	255/55R19	107T	8J	265	763	975	300
20″	265/50R20	111T	8.5J	277	774	1090	340

Rim Diameter	Size	LI/SI	Measuring Rim	Inflatable Section Width(mm)	Overall Diameter(mm)	Max. Load(kg）	Max. Pressure(kPa)
17″	215/65R17	103T XL	6.5J	221	712	875	340
17″	235/45R17	97T XL	8J	236	644	730	340

Rim Diameter	Size	LI/SI	Measuring Rim	Inflatable Section Width(mm)	Overall Diameter(mm)	Max. Load(kg）	Max. Pressure(kPa)
18″	215/55R18	95T	7J	226	693	690	300
	235/50R18	101T XL	7.5J	245	693	825	340
	245/40R18	97T XL	8.5J	248	653	730	340
	225/55R18	102T XL	7J	233	705	850	340
	255/60R18	112T XL	7.5J	260	763	1120	340

Rim Diameter	Size	LI/SI	Measuring Rim	Inflatable Section Width(mm)	Overall Diameter(mm)	Max. Load(kg）	Max. Pressure(kPa)
19″	245/45R19	98T	8J	243	703	750	300
	255/50R19	103T	8J	265	739	875	300
	255/55R19	107T	8J	265	763	975	300

Rim Diameter	Size	LI/SI	Measuring Rim	Inflatable Section Width(mm)	Overall Diameter(mm)	Max. Load(kg）	Max. Pressure(kPa)
20″	265/50R20	111T	8.5J	277	774	1090	340

size

Rim Diameter	Size	LI/SI	Measuring Rim	Inflatable Section Width(mm)	Overall Diameter(mm)	Max. Load(kg）	Max. Pressure(kPa)
17″	215/65R17	103T XL	6.5J	221	712	875	340
17″	235/45R17	97T XL	8J	236	644	730	340
18″	215/55R18	95T	7J	226	693	690	300
	235/50R18	101T XL	7.5J	245	693	825	340
	245/40R18	97T XL	8.5J	248	653	730	340
	225/55R18	102T XL	7J	233	705	850	340
	255/60R18	112T XL	7.5J	260	763	1120	340
19″	245/45R19	98T	8J	243	703	750	300
	255/50R19	103T	8J	265	739	875	300
	255/55R19	107T	8J	265	763	975	300
20″	265/50R20	111T	8.5J	277	774	1090	340

Rim Diameter	Size	LI/SI	Measuring Rim	Inflatable Section Width(mm)	Overall Diameter(mm)	Max. Load(kg）	Max. Pressure(kPa)
17″	215/65R17	103T XL	6.5J	221	712	875	340
17″	235/45R17	97T XL	8J	236	644	730	340

Rim Diameter	Size	LI/SI	Measuring Rim	Inflatable Section Width(mm)	Overall Diameter(mm)	Max. Load(kg）	Max. Pressure(kPa)
18″	215/55R18	95T	7J	226	693	690	300
	235/50R18	101T XL	7.5J	245	693	825	340
	245/40R18	97T XL	8.5J	248	653	730	340
	225/55R18	102T XL	7J	233	705	850	340
	255/60R18	112T XL	7.5J	260	763	1120	340

Rim Diameter	Size	LI/SI	Measuring Rim	Inflatable Section Width(mm)	Overall Diameter(mm)	Max. Load(kg）	Max. Pressure(kPa)
19″	245/45R19	98T	8J	243	703	750	300
	255/50R19	103T	8J	265	739	875	300
	255/55R19	107T	8J	265	763	975	300

Rim Diameter	Size	LI/SI	Measuring Rim	Inflatable Section Width(mm)	Overall Diameter(mm)	Max. Load(kg）	Max. Pressure(kPa)
20″	265/50R20	111T	8.5J	277	774	1090	340
